Vibration Monitoring for Centrifugal PumpsPCH vibration monitor for pumps







Vibration monitoring for centrifugal pumps is the most widely used and the most reliable method for keeping your pumps in good condition.

Centrifugal pumps are subject to massive centrifugal forces, and pump breakdowns are not only costly, but also dangerous.

By monitoring and analysing the vibration signal of your dynamic pumps, you can detect pump problems and schedule pump repairs before the problems result in pump damage and unplanned downtime.










Find a monitoring solution for your centrifugal pump:





Contact
a consultant







Vibration monitoring system for pump monitoring

With PCH Engineering’s range of vibration monitors and vibration sensors, you have a wide selection of simple or advanced vibration monitoring equipment depending on your requirements.

Our pump monitoring solutions offer data in real time, local alarms, adjustable alarm levels and offline FFT analysis. They easily integrate with your existing DCS, SCADA system or PLC through hardwired 4-20 mA signals, alarm relays or various interfaces such as Modbus TCP/RTU, ProfiNet, OPC UA or IIoT (REST).












Best pump monitoring solutions




PCH 1106: ISO 10816-3/20816-3 compliant vibration sensor

If you are looking for a simple monitoring solution for a single pump, we recommend the PCH 1106 vibration sensor.

The PCH 1106 Vibration Sensor has an excellent frequency response curve up to 1000 Hz, so you are sure to be monitoring the higher frequencies such as gear mesh or blade pass frequencies in the centrifugal pump without any damping of the signal.










PCH 1420: IoT-enabled 4-channel vibration monitor

If you wish to monitor several pumps, the PCH 1420 vibration monitor provides a wide range of data and is even IoT enabled.

This advanced vibration monitor has a redundant SIL 2 safety relay, adjustable alarm levels, time waveform recordings and essential bearing fault detectors: Envelope, Crest factor and Kurtosis.

It has user-defined bandpass filters from 0.7 Hz up to 11,500 Hz.














Vibration monitoring for centrifugal pumps increases pump lifespan

How to monitor vibrations in centrifugal pumps

A centrifugal pump has three rotating components: the shaft, the impeller(s) and the bearings.

Vibrations from the rotating parts are transmitted through the pump’s rotating shaft through the pump bearings to the bearing housing.

PCH vibration monitoring solutions measure pump vibrations by monitoring the bearing housing using a combination of vibration sensors and monitors.

The sensors detect the vibration level of the pump bearing housing and deliver the measuring results as either 4-20 mA, alarm relay outputs or by Modbus TCP. More enhanced monitors can also be used for time waveform and frequency data analysis.





Where to mount vibration sensors on centrifugal pumps

The vibrations of the shaft, impeller and bearings can all be measured by mounting vibration sensors on the bearing housing of the pump.

You should always measure in the radial direction (90o) of each bearing, if at all possible.

Mount the sensor on solid metal on the bearing housing. Make sure that the surface is clean and corrosion free.

On a smaller pump, one measuring point often suffices. On a larger pump motor (more than 75 cm between the bearings), you need two measuring points – one on each bearing.

Vibrations from the shaft and impeller/fan will transmit to the motor bearing. Never measure impeller vibrations on the impeller housing as this is weak and unstable and will provide faulty vibration data. It is better to measure impeller vibrations at the bearing location.










Vibration limits for centrifugal pumpsISO 10816 - ISO 20816 vibration limits for centrifugal pumps

An operating centrifugal pump will have some natural vibration. That is why it is important to determine the vibration signal limits for your particular pump.

You can use ISO 10816 or ISO 20816 standard vibration limits as guidelines, but you should always determine the vibration limit values for your centrifugal pumps to make sure that they are operating under optimal conditions. All PCH vibration monitors are certified according to the relevant ISO standards.

Detection of stages 1 and 2 bearing problems as well as cavitation require high frequency broad band monitoring of up to 10 kHz in acceleration. No ISO limits are defined for this.







Quality measurements depend on choosing the right vibration sensors and monitors for the job.

Our consultants are here to advise you on the best vibration monitoring solution for your centrifugal pumps.







Contact
a consultant










Monitor bearing failure in centrifugal pumps



6 most common problems in centrifugal pumps

The six most common causes of centrifugal pump failure cal all be detected at an early stage by monitoring the vibration signal of the pump with vibration monitoring solutions from PCH Engineering.

Continuous monitoring of your centrifugal pump allows you to understand its normal vibration patterns and to collect trend data for analysis.



Pump cavitation

Cavitation is when vapour pockets form and collapse as they pass through the pump impeller.

This can severely damage the centrifugal pump and impeller. It typically generates higher frequency broadband energy.



Pump flow pulsation

Pump flow pulsation develops when a centrifugal pump operates near its shut-off head.

It is often indicated by unstable peaks that increase and decrease in time with the flow pulsation.





Damaged impeller from centrifugal pump

Imbalanced pump impeller

Imbalance of pump impellers have a strong impact on the pump’s efficiency and bearing life. For the centrifugal pump to function optimally, it relies on constant, high speed rotation of its impeller.

Imbalance in the pump impeller can cause overheating, shaft deflection, bearing failure, excessive vibration, mechanical seal or packing failure or a complete breakdown of the pump.

For center-hung impellers, unbalance is often indicated by increased axial vibration. The vibration level increases as a result of the impeller movement being obstructed.

For overhung impellers, unbalance is often indicated by unsteady radial phase readings.









Centrifugal pump maintenanceBent pump shaft

If the shaft of the pump is bent, it tends to cause high axial vibration with axial phase differences tending towards 180 degrees on the same rotor.

A bent pump shaft can deflect and damage the whole system.




Pump shaft misalignment

In direct drive pumps, pump shaft misalignment occurs when the centerlines of two shafts are misaligned, or where the centerlines are parallel, but offset from each other.








Pump bearing housing corrosionPump bearing problems

Pump bearings can fail as a result of pump overload, corrosion, poor maintenance, overheating or simple wear, as bearings tend to have a shorter lifespan than the pump itself.

Bearing failure is typically indicated by an increase in the high frequency vibrations.













Find a vibration monitoring solution to protect your centrifugal pumps from the most common problems in pumps.
